6
2.2 CONTROL FUNCTIONS
Accelerator Pedal
Controls the forward movement and speed of the riding mower.
Brake Pedal
Slow down and stop the movement of the riding mower.
Charging Socket
When charging, rst connect the wire between the power supply and
the charger, and then connect the charger and the mower.
Always leave charger plugged in while not in use.
When powered, the LED indicator on the charger will illuminate to
indicate the charger’s status.
Cruise control button
Press to continue forward at a set speed without needing to press the
accelerator pedal.
Cutterhead Lifting Handle
Raise or lower the height of the cutting deck.
Mower Motor Switch
Lift the switch upwards to start the mower blades.
Push the switch to stop the mower blades.
Mower Motor Switch
Battery Indicator
Headlight Switch
Power Switch
USB Port
Run Time
Reverse Mowing
Option
Cruise Control
Button
