13
Flange nut. The recommended torque is 25 ± 2N.m.
2. After installing the shaft, put the decorative tube on the shaft.
3. Put ange washer, bushing, ange washer, Steering wheel hub on the shaft.
4. Then install steering wheel and at washer in the order and direction as
shown in the gure. The mounting points of the steering wheel and
the steering wheel base are aligned and xed with ange nut. The
recommended torque is 24 ± 2N.m.
5. Finally install the steering wheel cover on steering wheel
Once assembly is complete, set the cutting deck to its maximum height, then
position a ramp next to the frame bottom, and slowly and carefully drive the product
off the frame.
NOTE
Use care when driving the product off or the frame, and step on the
brake pedal as needed to control the speed. The product freely rolls if
it is moved on an inclined surface without stepping on the brake pedal
or engaging the parking brake. Failure to follow these instructions can
result in loss of control and result in death, serious personal injury, or
property damage.
If no ramp is available, slowly and carefully drive the product off the
frame in reverse while looking down and behind. Driving the product off
the frame in the forward direction without a ramp can cause damage to
the cutting deck.
3.5 CHARGING THE PRODUCT
Mower batteries must be charged overnight before rst use. To verify mower
batteries are fully charged, check the battery level indicator.
NOTE
Charger input power specication: AC 100V~ 240V, frequency 50/60Hz.
The charger is equipped with a plug featuring a grounding pin and must
be plugged into a matching standard three prong outlet that has been
properly installed and grounded in accordance with all local codes and
ordinances.
In order to prolong the service life of the battery, it is recommended to
charge it once every three months.
When the battery power is lower than 25%, the mowing motor will
automatically shut down.
BM3775
