5.2 ADJUSTING THE CUTTING DECK HEIGHT
NOTE
 During equipment transportation, set the height of the cutter head from
the ground to 3 inches.
 DO NOT release the cutterhead lifting handle quickly, it may cause harm
by squeezing or pulling the operator’s hand.
Raise the Cutting Deck
1. Stop the mower as described in Section 4.2.
2. Hold the cutterhead lifting handle, push left to disengage from slot, move
toward the back of the mower, then push right into slot to secure.
Lower the Cutting Deck
1. Stop the mower as described in Section 4.2.
2. Hold the cutterhead lifting handle, push left to disengage from slot, move
toward the front of the mower, then push right into slot to secure.
1
4 5 6
2 3
ON
OFF
