9
3. GETTING STARTED
Setup of your riding lawn mower is designed to get you up and running as quickly as
possible. Cut the four corners of the carton from top to bottom instead of attempting
to lift it out of the box.
3.1 UNPACKING
WARNING!
If any parts on the 2.3 section are already assembled to the
product when you unpack it, verify that the part is assembled
correctly and properly tightened. Use of a product that may have
been improperly assembled could result in serious personal
injury.
To prevent accidental starting that could cause serious personal
injury, always remove the start key from the product when
assembling the parts.
1. Remove the bolts securing the corner and side braces to the frame bottom,
then lift the braces to remove.
2. Cut the nylon straps securing the front and rear wheel axles to the frame.
3. Remove the boxes containing loose parts, assembly hardware, and
documentation.
4. Remove and set aside all accessible packaging and wrap from the unit and
BM3775
