Benchmark DAC3 HGC - Balanced Analog Outputs; Unbalanced Analog Outputs; HPA2 TM Headphone Outputs

Instruction Manual for DAC3 HGC and DAC3 L with 2.X Firmware Page 66
Balanced Analog Outputs
Number of Balanced Analog Outputs
2
Output Connector
Gold-Pin Neutrik™ male XLR
Output Impedance
60 Ohms (Attenuator off)
425 Ohms (Attenuator = 10 dB)
135 Ohms (Attenuator = 20 dB)
Analog Output Clip Point
+29 dBu
Factory Set Bypass Level (with 0 dBFS digital input)
+24 dBu (Attenuator = 0 dB)
Volume Control Range (with 0 dBFS digital input)
Off to +27.5 dBu (Attenuator off)
Off to +17.5 dBu (Attenuator = 10
dB)
Off to +7.5 dBu (Attenuator = 20 dB)
Output Level Variation with Sample Rate
< +/- 0.006 dB
Unbalanced Analog Outputs
Number of Unbalanced Analog Outputs
4
Output Connector
RCA
Output Impedance
30 Ohms
Analog Output Clip Point
+13.5 dBu (3.7 Vrms)
Factory-Set Home Theater Bypass Output Level (with 0
dBFS digital input)
+8.2 dBu (2 Vrms)
Output Level Range (with 0 dBFS digital input)
Off to +11.7 dBu (3 Vrms)
Output Level Variation with Sample Rate
< +/- 0.006 dB
HPA2
TM
Headphone Outputs
Number of Headphone Outputs
2
Output Connectors
¼” TRS with switch on left-hand jack
Output Impedance
< 0.11 Ohms
Output Level Control
Stereo Control on Front Panel
Output Level Range (with 0 dBFS digital input)
Off to +21.5 dBu (9.2 Vrms)
Output Power
1.25 W into 30 Ohms
Maximum Output Current
250 mA
Overload Protection (independent per channel)
Current limited at 300 mA, Thermal
Bandwidth
> 500 kHz, -0.35 dB at 200 kHz
THD+N at 20 mW
-108 dB (0.0004%) into 300 Ohms,
-100 dB (0.0010%) into 30 Ohms
