General Information
35
Side Object Detection
Normal Operation
When an object is detected within the sensor’s detection zone, the driver display illuminates the red detect lamp. During normal operation,
the display will toggle between illuminating either the yellow or the red lamps, but never both at the same time (See SOD Failure Diagnostic
Procedure).
Alert Tone
If the turn signal is active when an object is detected, the Driver Display Unit will sound an alert tone. An alert tone is heard only once each
time the turn signal is activated. The sensor is wired to the turn signal on the same side of the vehicle in which the sensor is mounted (ie:
RH Turn Signal causes a RH mounted SOD display to tone).
