General Information
36
Side Object Detection
Diagnostic Trouble Code (DTC) Isolation Procedures
System Diagnostic Trouble Code (DTC)
(Both Red and Yellow Lamps ON)
Overview
The Side Object Detection (SOD) Driver Display Unit illuminates both the red and yellow lamps to indicate a system Diagnostic Trouble
Code (DTC).
Diagnostic Trouble Code (DTC) Detection
Whenever the SOD Driver Display looses communications with the side sensor, or if the sensor reports an internal failure, the display will
illuminate both the red and yellow lamps.
Symptom
The Side Object Detection system will fail to detect objects in its detection zone.
Possible Causes
 • BrokenorshortedwirebetweentheSODdisplayandtheSODsensor
 • MalfunctioningSideSensor
Repair Procedure
Condition Steps to Perform
Red and Yellow ON 1. Disconnect the Driver Display and the Side Sensor from the interconnect harness.
2. Test the resistance between Pin-3 of the Driver Display harness connector and chassis
ground.
   a. Ifgreaterthan100Kohms,continuetonextstep.
   b. Iflessthan100Kohms,testfailed.Repairharness.
3. Test resistance between Pin-3 of the Driver Display harness connector and Pin-3 of the
Side Sensor harness connector.
a. If less than 0.9 ohms, continue to next step.
b. If greater than 0.9 ohms, test failed. Repair harness.
4. Test complete. Replace Side Sensor.
