HD-9 Series Four-Post Lifts 10 P/N 5900123 — Rev. M — February 2020
Model HD-9 HD-9XL HD-9XW
Lifting capacity 9,000 lbs / 4,082 kg
Max capacity at Front Axle 4,500 lbs / 2,041 kg
Max capacity at Rear Axle 4,500 lbs / 2,041 kg
a Min. runway height
4.5" / 114 mm
b Maximum rise
70" (5.10 feet) / 1,778 mm
82" (6.10 feet) /
2,083 mm
c Maximum lifting height
75" (6.3 feet) / 1,903 mm
87" (7.3 feet) /
2,208 mm
d Overall width
110.25" (9.2 feet) / 2,800 mm
e Outside length
174" (14.6 feet) /
4,420 mm
198" (16.6 feet) / 5,029 mm
f Overall length
200" (16.8 feet) /
5,080 mm
224" (18.8 feet) / 5,690 mm
g Height of post
88" (7.4 feet) / 2,235 mm
100" (8.4 feet) /
2,540 mm
h Distance between posts
100.25" (8.4 feet) / 2,555 mm
i Drive-thru clearance
86.5" (7.3 feet) / 2,197 mm
j Runway width
19" / 482 mm
k Runway length
164.5" (13.9 feet) /
4,178 mm
188.5" (15.9 feet) / 4,788 mm
l Width between runways
38" / 963 mm
or
44.25" / 1,127 mm
m Runway centerline
56.5" – 63.25" / 1,435 –
1,610 mm
n Outside edge of runways
75.5" – 82.25" / 1,918 – 2,092 mm
Min. wheelbase @ rated
capacity
1
115" (9.7 feet) /
2,921 mm
135" (11.3 feet) / 3,429mm
Min. wheelbase @ 75 capacity
1
100" (8.4 feet) /
2,540 mm
115" (9.7 feet) / 2,921 mm
Min. wheelbase @ 50 capacity
1
85" (7.1 feet) /
2,159 mm
95" (7.11 feet) / 2,413 mm
Min. wheelbase @ 25 capacity
1
70" (5.10 feet) /
1,778 mm
80" (6.8 feet) / 2,032 mm
Locking positions 14, spaced every 4" /
102 mm
14; spaced every 4" /
102 mm
17; spaced every 4" /
102 mm
Motor 220 VAC, 60 Hz, 1 Ph (special voltages available upon request)
1
The Lift supports less weight than its rated capacity if the Vehicle’s wheelbase is shorter; this is
because the wheels are closer to the middle of the Runways, where there is less strength. For
example, the maximum weight allowed on the Lift for a Vehicle with a wheelbase of 85" is 50
percent of the Lift’s rated capacity (or 4,500 lbs when the rated capacity is 9,000 lbs).
Specifications subject to change without notice.
