BendPak HD-9ST - Introduction

2232.0mm
87.874in
1308.9mm
51.532in
1903.0mm
74.921in
83.0mm MAX
3.268in MAX
4.090in
103.9mm
4.764in
121.0mm
70.157in
1782.0mm
A
B
2292.0mm
90.236in
4178.0mm
164.488in
482.0mm
18.976in
173.937in
4418.0mm
200.612in
5095.6mm
34.606in MAX
879.0mm MAX
7.559in
192.0mm
100.236in
2546.0mm
68.858in
1749.0mm
DRIVE THRU
FRONT VIEW
4.010in
101.9mm
DETAIL A
SCALE 1 : 10
4.149in
105.4mm
DETAIL B
SCALE 1 : 10
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
AE
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260526
HD-9ST PRODUCTION
LIFT VER K (CE CERT)
1:45
SCALE:
