BendPak XPR-10 Series User Manual

XPR-10 Series Two-Post Lifts 11 P/N 5900951 — Rev. D — May 2019
Model
XPR-10AS / -LP XPR-10AS-168 / -168-LP
Lifting capacity 10,000 lbs / 4,536 kg
Maximum Capacity Front Axle 5,000 / 2,268 kg
Maximum Capacity Rear Axle 5,000 / 2,268 kg
A – Rise
69" / 1,753 mm
B – Lifting Height w/Pad*
73.75" / 1,872 mm
C - Maximum Lifting Height*
78.25" / 1,990 mm
D – Minimum Height w/Pad
4.75" / 119 mm
E – Height Overall
144.75" / 3,678 mm 168.75" / 4,284 mm
F – Width Overall (narrow)
137" / 3,480 mm
F – Width Overall (wide)
145" / 3,684 mm
G – Outside Posts (narrow)
133.25" / 3,386 mm
G – Outside Posts (wide)
141.25" / 3,590 mm
H – Inside Posts (narrow)
106.25" / 2,700 mm
H – Inside Posts (wide)
114.25" / 2,903 mm
I – Drive-Thru Width (narrow)
93.75" / 2,382 mm
I – Drive-Thru Width (wide)
101.75" / 2,585 mm
J – Floor to Top Switch
140" / 3,558 mm 164" / 4,164 mm
K – Front Arm Reach (min)
23.5" / 595 mm
K – Front Arm Reach (max)
43.75" / 1,110 mm
L – Rear Arm Reach (min)
40.25" / 1,024 mm
L – Rear Arm Reach (max)
58" / 1,474 mm
Motor 220 VAC, 60 Hz, 1 Phase
Time to Full Rise ~45 seconds
Maximum hydraulic pressure 2500
Sound <70 dB
* Lifting Height w/Pad is maximum lifting height with Pads at lowest height, no adapter. Maximum
Lifting Height is maximum lifting height with Pads at top height and with the 2.5" / 63 mm adapter.
Specifications subject to change without notice.
