BendPak XPR-10 Series User Manual

XPR-10 Series Two-Post Lifts 12 P/N 5900951 — Rev. D — May 2019
Model
XPR-10XLS / -LP XPR-10XLS-168 / -168-LP
Lifting capacity 10,000 lbs / 4,536 kg
Maximum Capacity Front Axle 5,000 / 2,268 kg
Maximum Capacity Rear Axle 5,000 / 2,268 kg
A – Rise
75" / 1,905 mm
B – Lifting Height w/Pad*
79.75" / 2,025 mm
C - Maximum Lifting Height*
84.5" / 2,143 mm
D – Minimum Height w/Pad
4.75" / 120 mm
E – Height Overall
156.75" / 3,983 mm 180.75" / 4,589 mm
F – Width Overall (narrow)
132" / 3,353 mm
F – Width Overall (wide)
145" / 3,683 mm
G – Outside Posts (narrow)
126.75" / 3,219 mm
G – Outside Posts (wide)
139.75" / 3,549 mm
H – Inside Posts (narrow)
105.5" / 2,679 mm
H – Inside Posts (wide)
118.5" / 3,009 mm
I – Drive-Thru Width (narrow)
93" / 2,364 mm
I – Drive-Thru Width (wide)
106" / 2,694 mm
J – Floor to Top Switch
152" / 3,863 mm 176" / 4,469 mm
K – Front Arm Reach (min)
25.5" / 646 mm
K – Front Arm Reach (max)
49.5" / 1,255 mm
L – Rear Arm Reach (min)
32.25" / 820 mm
L – Rear Arm Reach (max)
52.5" / 1,333 mm
Motor 220 VAC, 60 Hz, 1 Phase
Time to Full Rise ~45 seconds
Maximum hydraulic pressure 2500
Sound <70 dB
* Lifting Height w/Pad is maximum lifting height with Pads at lowest height, no adapter. Maximum
Lifting Height is maximum lifting height with Pads at top height and with the 2.5" / 63 mm adapter.
Specifications subject to change without notice.

BendPak XPR-10 Series Specifications

General

Capacity	10, 000 lbs
Rise Time	45 seconds
Voltage	220V
Motor	2 HP
Minimum Height	4.5 inches
Overall Height	145" / 3, 683 mm
