BendPak XPR-10 Series User Manual

XPR-10 Series Two-Post Lifts 69 P/N 5900951 — Rev. D — May 2019
If any of the Adapters are not making solid contact with the Lifting Points, carefully lower the Lift
and start over again; the Adapters
must make solid contact with the Lifting Points.
12. Rock the Vehicle to make sure the Vehicle is stable and balanced.
If the Vehicle is
not stable and balanced, lower the Lift back to the ground and start over.
If the Vehicle
is stable and balanced, you can raise it to the desired height.
⚠ DANGER Do not raise the Lift further until you are certain the Vehicle on the Lift is both stable
and balanced. If the Vehicle is
not stable and balanced, it could fall, which could
damage the Vehicle, damage the Lift, or injure or kill anyone under the Vehicle.
13. Press and hold the Up Button.
14. Listen as the Lift passes the Safety Locks; you should hear each side pass by the Safety Locks at
approximately the same time.
15. When the Vehicle reaches the desired height, go past the next Safety Lock position (you will hear
the clank as it passes), then release the Up Button.
16. Press and hold the Lowering Handle, which lowers the Lift onto the Safety Lock position you just
passed. (Do not hold the Safety Lock Release Handle, that is for lowering the Lift to the ground.)
17. When the Lift stops moving down, it is engaged on its Safety Locks; release the Lowering Handle.
Do not leave the Lift controls unless the Lift is engaged on its Safety Locks or
fully lowered.
18. Recheck the Adapters to make sure they are all still making solid contact with the Lifting Points.
19. Make sure the Lift is engaged on the same Safety Lock on both Posts. You do not want the Lift
engaged on Safety Locks of two different heights or one Safety Lock engaged but the other not.
20. Begin work on the Vehicle.
To raise Lift:
1. Press and hold Up Button.
2. When Lift is just past desired
height, release Up Button.
3. Press and hold Lowering
Handle.
Do not press and hold the
Safety Lock Release Handle.
If you do, the Lift will
continue to lower and will not
engage on its Safety Locks.
Lift engages on its Safety
Locks and stops moving;
release Lowering Handle
when Lift stops.
Only leave Lift on Safety
Locks or fully lowered.
To lower Lift:
1. Press and hold Up Button
for two to three seconds.
This moves Lift off its Safety
Locks.
2. Press and hold Safety Lock
Release Handle
and
Lowering Handle.
Lift begins lowering.
3. When Lift is fully lowered,
release Safety Lock
Release Handle and
Lowering Handle.
Only leave Lift on Safety
Locks or fully lowered.

BendPak XPR-10 Series Specifications

General

Capacity	10, 000 lbs
Rise Time	45 seconds
Voltage	220V
Motor	2 HP
Minimum Height	4.5 inches
Overall Height	145" / 3, 683 mm
