4
CLEARANCES
XPR-10CX
XPR-10ACX
LIFT HEIGHT CLEARANCE NOTE: There must be a 1” MIN distance from top of lift to nearest obstruction.
NOTE:
SUBTRACT 6-1/2” FROM MINIMUM
NEAREST WALL AND MINIMUM
NEAREST BAY DIMENSION FOR
XPR-10C.
NOTE:
SUBTRACT 6-1/2” FROM MINIMUM
NEAREST WALL AND MINIMUM
NEAREST BAY DIMENSION FOR
XPR-10ACX.
