41
DIMENSIONS ARE IN MM
☺
ITEM
NO
PART NUMBER
DESCRIPTION
QTY
REV
1 801048
XPR-9FD/FDX POWER SIDE POST ASSEMBLY
1
C
2 801049
XPR-9FD/FDX OFFSIDE POST ASSEMBLY
1
C
3 800673
XP/XPR-9FD
GROUND PLATE
1
A-001
4 800869
XPR-9FD/FDX LIFT HEAD ASSEMBLY
2
C
5 800679
XP/XPR-9FD/FDX TOP EQUALIZER PULLEY PLATE ASSEMBLY
2
B
6 700207
CYLINDER ASSEMBLY Ø2.0 x 69
2
A
7 800680
CYLINDER SPACER
2
A
8
AB-1551 POWER UNIT
POWER UNIT
1
--
9 800112
OFF SIDE COVER
2
A
10 800191
SAFETY CLEVIS PIN
2
C
11 800100
XP/XPR POWER SIDE SAFETY WELDMENT
1
B
12 800104
XP/XPR OFF SIDE SAFETY WELDMENT
1
B
13 5550178
FTG TEE -04JIC -04JIC -06NPT
1
--
14 5550183
FTG ELB -06 JIC -06L ORB
1
--
15 5580210
Ø2.4mm OVAL CABLE CRIMP
1
--
16 5545347
WASHER, M12 FLAT WASHER
2
--
17
16 DIA. HAIRPIN COTTER
Ø3.75 x 68mm
2
--
18 800200
2.5 WIRE DIA., Ø25.5x150 LG.
2
B
19
HN M12 X 1.75
HEX NUT
2
--
20 5535025
NUT M18 x 2.5 NL
2
--
21 5545342
WASHER M18 FLAT
2
--
22 5530010
HHB M8 x 1.25 x 25
4
--
23
8 x 15 x 2 LW
SPRING LOCK WASHER
4
--
24
HN M8 x 1.25
HEX NUT M8 x 1.25
4
--
25
HHB M10 x1.5 x 38 HEX HEAD BOLT M10 x 1.5 x 38
4
--
26 5530114
HHB M8 x 1.25 x 18
4
--
27
HN M10 X 1.5
HEX NUT
4
--
28
10 x 18 x 2.3 LW
SPRING LOCK WASHER
4
--
29
LP-800979
ALL XPR-9, XPR-10C/CX LOW PROFILE MEDIUM ARM ASSEMBLY
2
G
30
LP-800987
XPR-9F/FD/10C/AC LOW PROFILE TRIPLE TELESCOPING ARM
2
F
31 800750
XPR-9/10 LIFT HEAD PIN WELDMENT
4
C
32 800106
SLIP ON LIFT PAD ASSEMBLY
4
PRE-005
33 800207
MX/XP/XPR/RJ SHORT LIFT PAD EXTENSION (113mm LG.)
4
D
34 800208
MX/XP/XPR LONG LIFT PAD EXTENSION (182mm LG.)
4
D
35 801051
XP/XPR-9 CABLE ASSY Ø10mm x 10434
2
C
36
90° .56 MALE-.38 FEM
NPT
90° ELBOW MALE 9/16-18 UNF 37° FLARE TO FEMALE 3/8-18 NPT 2B 1"
LONG
1
--
37 5550147
FTG NPL -04 JIC x -04 NPT
2
--
38 800690
XP/XPR-9FD HYDRAULIC HOSE ASSY Ø6.35 x 1384mm
2
B
39 800692
XP/XPR-9FD HYDRAULIC HOSE ASSY Ø10 x 2896mm
1
B
40 800693
XPR-9F, XP/XPR-9FD Ø2.4mm x 7214 SAFETY CABLE
1
C
41
FG-801017
XPR-9F/FX/FD/FDX/10C/CX ARM FOOT GUARD (526mm)
2
E
42
FG-801014
XPR-9F/FD/10C/AC ARM FOOT GUARD (280mm)
2
E
43
HHB M10 x 1.5 x10
HEX HEAD BOLT
8
PRE-003
44 5715003
POWER UNIT VIBRATION DAMPENER
1
A
45
P-543
XPR PLASTIC COVER BLOCK 105x80
2
A
46
FG-800402
XP-9FD/FDX BOTTOM SHEAVE COVER L.H.
2
C
47
FG-800404
XP/XPR-9FD/FDX BOTTOM SHEAVE COVER R.H.
2
A
48 5730014
XP/XPR-9F/FD/FX/FDX POST ASSEMBLY LIFT HEAD FOOT GUARD R.H.
2
A
49 5730015
XP/XPR-9F/FD/FDX/FX POST ASSEMBLY LIFT HEAD FOOT GUARD L.H.
2
A
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
F
REPLACED PARTS:CABLE NUTS WITH
5535025, WASHER Ø50x20x3mmW WITH
5545342,POWER UNIT MOUNTING BOLTS
WITH 5530010,SAFETY COVER BOLTS WITH
5530114, CHANGED TEE FITTING
DESCRIPTION
06/05/2008
TM
00180
G
UPDATED REV ON ITEM IN BOM (XPR-9F,
XP/XPR-9FD
2.4mm x 6858LG. SAFETY
CABLE)
07/23/2008
GJ
00226
H
UPDATED DRAWING, UPDATED BOM
REVISION, OVAL SLEEVE WITH 5580210,
REPLACED WASHER WITH 5545347,
REPLACED .44x.38 TEE-FITT WITH 5550178,
REPLACED 90.375ElbowORing WITH
5550183, ADDED FOOT GUARDS FG-
800402, FG-800404, 5730014, 5730015
09/26/2008
TM
00220
SHEET 1 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
TD
XPR-9-FD
XPR-9FD LIFT ASSEMBLY
---
---
05/03/2007
DO NOT SCALE DRAWING
--
SCALE:
THIRD ANGLE PROJECTION
AC
01/10/2009
FG-800402,FG-800404,FG-801014,FG-801017, 5730014, 5730015
1.
& HHB M10 x 1.5 x 10 USED ONLY ON MODELS REQUIRING
FOOT GUARDS.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
NOTE: UNLESS OTHERWISE SPECIFIED
.
