45
DIMENSIONS ARE IN MM
☺
ITEM
NO.
PART NUMBER
DESCRIPTION
QT
Y
REV
1 800701
XP/XPR-12FD GROUND PLATE
1
A
2 801063
XPR-12-FD POWER SIDE POST ASSEMBLY
1
B
3 801065
XPR-12FD OFF SIDE POST ASSEMBLY
1
B
4 800877
XPR-12-FD LIFT HEAD ASSEMBLY
2
D
5 700126
CYLINDER ASSEMBLY Ø2.5 X 69
2
A
6 800706
XP/XPR-12FD TOP EQUALIZER PULLEY PLATE WELDMENT
2
B
7 800104
XP/XPR OFF SIDE SAFETY WELDMENT
1
B
8 800100
XP/XPR POWER SIDE SAFETY WELDMENT
1
B
9 800983
XPR-12C/FD TRIPLE TELESCOPING ARM
4
G
10 800106
SLIP ON LIFT PAD ASSEMBLY
4
PRE-005
11 800752
XPR-12C/FD LIFT HEAD PIN WELDMENT
4
C
12 800207
MX/XP/XPR/RJ SHORT LIFT PAD EXTENSION (113mm LG.)
4
D
13 800208
MX/XP/XPR LONG LIFT PAD EXTENSION (182mm LG.)
4
D
14
POWER UNIT
AB-1468 POWER UNIT
1
--
15 5530010
HHB M8 x 1.25 x 25
4
--
16
HN M8 x 1.25
HEX NUT M8 x 1.25
4
--
17
10 x 18 x 2.3 LW
SPRING LOCK WASHER
4
--
18
HHB M10 x1.5 x 38 HEX HEAD BOLT M10 x 1.5 x 38
4
--
19
HN M10 X 1.5
HEX NUT
4
--
20
8 x 15 x 2 LW
SPRING LOCK WASHER
4
--
21 5545347
WASHER, M12 FLAT WASHER
2
--
22
HN M12 X 1.75
HEX NUT
2
--
23 5530114
HHB M8 x 1.25 x 18
4
--
24 5535011
NUT M22 x 2.5 NL
2
-
25 5545345
WASHER M22 x 50mm FLAT
2
--
26 5580210
Ø2.4mm OVAL CABLE CRIMP
1
A
27 800191
SAFETY CLEVIS PIN
2
C
28 800200
2.5 WIRE DIA., Ø25.5x150 LG.
2
B
29 5550183
FTG ELB -06 JIC -06L ORB
1
--
30 800112
OFF SIDE COVER
2
A
31
90° .56 MALE-.38
FEM NPT
90° ELBOW MALE 9/16-18 UNF 37° FLARE TO FEMALE 3/8-18 NPT 2B 1"
LONG
1
--
32 5550178
FTG TEE -04JIC -04JIC -06NPT
1
--
33 801067
XP/XPR-12 CABLE ASSY Ø12mm x 10801
2
D
34 5550147
FTG NPL -04 JIC x -04 NPT
2
--
35 800393
XP-12F Ø6.35 x 1562LG. HYDRAULIC CYLINDER HOSE ASSEMBLY
2
B
36 800721
XP/XPR-12-FD Ø2.4 x 7400mm LG. SAFETY CABLE
1
B
37 5570126
XP/XPR-12FD HYDRAULIC HOSE ASSY Ø10 x 3150mm
1
A
38
FG-801016
XPR-12C/FD TRIPLE TELESCOPING ARM FOOT GUARD (493mm)
4
D
39
HHB M10 x 1.5 x10
HEX HEAD BOLT
8
--
40 5715003
POWER UNIT VIBRATION DAMPENER
1
A
41
P-543
XPR PLASTIC COVER BLOCK 105x80
2
A
42
FG-800403
XP-12FD BOTTOM SHEAVE COVER RH
2
B
43
FG-800445
XP/XPR-12FD BOTTOM SHEAVE COVER LH
2
A
44 5730016
XP/XPR-12C/F/FD/15/18C POST ASSEMBLY LIFT HEAD FOOT GUARD L.H.
2
A
45 5730017
XP/XPR-12C/F/FD/15/18C POST ASSEMBLY LIFT HEAD FOOT GUARD R.H.
2
A
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
E
REPLACED PARTS:CABLE NUTS WITH 5535011,
WASHER Ø50x20x3mmW WITH
5545345,POWER UNIT MOUNTING BOLTS WITH
5530010,SAFETY COVER BOLTS WITH 5530114,
CHANGED TEE FITTING DESCRIPTION
06/06/2008
TM
00180
F
UPDATED REV ON ITEMS IN BOM (800721
SAFETYCABLE
2.4 x 7400mm LG.)
07/25/2008
GJ
00226
G
UPDATED DRAWING, UPDATED BOM
REVISION, OVAL SLEEVE WITH 5580210,
REPLACED WASHER WITH 5545347,
REPLACED .44x.38 TEE-FITT WITH 5550178,
REPLACED .25-.4375 PIPE WITH 5550147,
REPLACED 90.375NPT-.56J MAORB WITH
5550183, REPLACED 800720 WITH 5570126,
REPLACED 801105 WITH 5715003, ADDED
FOOT GUARDS FG-800403, FG-800445,
5730016 & 5730017
09/30/2008
TM
00220
SHEET 1 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
G
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TD
XPR-12-FD
XPR-12-FD LIFT ASSEMBLY
---
---
05/23/2007
DO NOT SCALE DRAWING
--
SCALE:
THIRD ANGLE PROJECTION
AC
01/10/2009
FG-800403, FG-800445, FG-801016, 5730016, 5730017 &
1.
HHB M10 x 1.5 x 10 USED ONLY ON MODELS REQUIRING FOOT GUARDS
2.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
3.
---
