51
DIMENSIONS ARE IN MM
☺
1
4
3
5
2
ITEM NO.
PART NUMBER
DESCRIPTION
QTY
REV
1 5245106
XPR-9FXS LIFT SUPERSTRUCTURE
1
D
2 5250135
XPR-9FXS PARTS BOX
1
D
3 5215195
XPR-9/10C/CX LOW PROFILE MEDIUM ARM
ASSEMBLY
2
A
4 5210741
XPR-9FX/FDX/FSX/ 10ACX/10CX LOW PROFILE
TRIPLE TELESCOPING ARM ASSEMBLY
2
A
5 5215226
XP/XPR-9FD/FDX, XPR-9FS/FSX TOP EQUALIZER
PULLEY PLATE ASSEMBLY
2
B
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
B
UPDATED BOM REVSIONS, ADDED 5215226,
5215741 AND 5215195
02/18/2010
TM
00293
C
UPDATED BOM REVISIONS
04/13/2010
TM
00346
D
UPDATED BOM REVISIONS
04/30/2010
AC
00350
SHEET 1 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
AC
5260046
XPR-9FSX RECEIVED LIFT
---
---
11/24/2009
DO NOT SCALE DRAWING
1:30
SCALE:
THIRD ANGLE PROJECTION
TM
05/31/2010
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
1.
