TRK 502/ 502X
22
PRIMARY PARTS
The computers integrated in the ABS compare vehicle speed with wheel speed. Since non-recommended tires
can aect wheel speed, they may confuse the computers, which can extend braking distance.
Use of non-recommended tires may cause malfunctioning of ABS and can lead to extended braking distance.
The rider could have an accident as a result. Always use recommended standard tires for this vehicle.
WARNING
!
○ ABS indicator light may come on under certain extreme riding condition. For example, wheelie, stoppie,
or burn-out, rear-wheel drifting, or any maneuvers may cause the front and rear wheel to have dierent rotation
status. In this case, rst turn the ignition key to “OFF” , and then back to “ON” . ABS indicator light goes o by
this operation, but if ABS indicator light remains lit after the vehicle runs at the speed of approximately 5 km/h or
above, you should have the bike checked by an authorized Benelli dealer.
○ When the ABS is functioning, you may feel a pulsing in the brake lever or pedal. This is normal. You don’ t
need and should not stop applying brakes when this specic pulsing feeling appears.
○ ABS does not function at speeds of approximate 5 km/h or below.
○ ABS does not function if the battery is discharged.
!
NOTICE

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
