TRK 502/ 502X
41
d. Take down the negative terminal （－） rst, and then the positive terminal（＋）;
e. Take out the battery gently.
Install the battery in the reverse order of removal.
Please operate on the following requirements for the rst use：
Remove the sealing paper on the battery. Inject specially supplied electrolyte into the battery and put on the
battery sealing plug. Leave it for 30 minutes for full chemical reaction and then you can use the battery.
For the new battery, initial charge after electrolyte lling will extend its service life. This operation shall be
performed by your local dealers.
Connect the wire polarities correctly. Positive wire (red) shall be connected with the positive terminal（＋）; and
negative wire（black）to the negative terminal（－）. Tighten terminal bolts. Clean frequently the erosive
substances on the terminals with a wire brush while in use.
Please operate according to the following requirements while lling electrolyte into the maintenance-free battery:
INSPECTION& MAINTENANCE
Attention：
Connect correctly the battery wires when the battery is re-installed. The red wire shall be connected with
the positive terminal （＋）; and black wire shall be connected to the negative terminal（－）. If the wires
are wrongly connected, it may damage the electrical system and the battery.
Power switch (key) shall be shut o while inspecting or replacing battery.

Benelli TRK 502X Specifications

General

Displacement	500 cc
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Max Power	47.6 HP (35 kW) @ 8500 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Steel Trellis
Ground Clearance	220 mm
Fuel Tank Capacity	20 liters
Weight (Dry)	213 kg
Engine Type	Liquid cooled, 4-stroke, 2-cylinder
Max Torque	46 Nm @ 6000 rpm
Fuel System	Electronic fuel injection
Front Suspension	50 mm upside-down fork, adjustable
Rear Suspension	Single shock, adjustable
Front Brake	320 mm double disc, ABS
Rear Brake	260 mm single disc, ABS
Front Tire	110/80 R19
Rear Tire	150/70 R17
Seat Height	840 mm
