TRK 502/ 502X
42
a. Place vertically the battery on a horizontal plane and remove the sealing tape.
b. Take out the electrolyte from the plastic bag. Open its cover strip and use it as lling plug for the battery.
c. Lift the electrolyte container upside down vertically and align the six lling ports of the container with the six
lling ports on the battery. Pull downward hard the electrolyte container so as to puncture the sealing tape on the
lling ports of electrolyte container. Electrolyte thus ows from the container to the battery. Check the three lling
pipes on both sides. At least there is one pipe that has bubbles coming out on each side, which means that
electrolyte lling begins normally. Attention: Please be sure not to tilt the container, or electrolyte lling may be
interrupted.
d. When you are sure that there is at least one pipe that has bubbles coming out on each side (three pipes on
each side), leave it there and keep the lling process over 20minutes.
If there is no pipe that has bubbles coming out on each side, tap slightly two to three times the bottom of the
electrolyte container and check again if there is at least one pipe that has bubbles coming out on each side (The
electrolyte cannot be taken down now).
e. When the electrolyte has completely owed through, tap the container bottom several times to drain residual
electrolyte; and then slowly pull out the electrolyte container.
INSPECTION BEFORE DRIVING
Attention:
Please do not tear or puncture the sealing tape on the lling port.
The cover strip can be kept as lling plug for the battery.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TRK 502X and is the answer not in the manual?

Benelli TRK 502X Specifications

General IconGeneral
Displacement500 cc
Bore x Stroke69 mm x 66.8 mm
Compression Ratio11.5:1
Max Power47.6 HP (35 kW) @ 8500 rpm
Transmission6-speed
Final DriveChain
FrameSteel Trellis
Ground Clearance220 mm
Fuel Tank Capacity20 liters
Weight (Dry)213 kg
Engine TypeLiquid cooled, 4-stroke, 2-cylinder
Max Torque46 Nm @ 6000 rpm
Fuel SystemElectronic fuel injection
Front Suspension50 mm upside-down fork, adjustable
Rear SuspensionSingle shock, adjustable
Front Brake320 mm double disc, ABS
Rear Brake260 mm single disc, ABS
Front Tire110/80 R19
Rear Tire150/70 R17
Seat Height840 mm
