Computer (cont’d)
Transaction display of: 999.999 for gallons,
9999.99 for liters and 6-digits for money with
programmable decimal point.
Electronic hose totals of:
99999999.999 for gallons (8.3)
999999999.99 for liters (9.2)
Electromechanical totalizer 9999999.
Hydraulics
Rotary meter rated at 70gpm maximum.
Built-in inlet check valves to keep the
hydraulics full and prevent meter/pulser count
-up when the submersible pump pressurizes
the system.
1-1/2” 2-Stage prepay/preset electric
solenoid valve.
Dual spin-on filters
1-1/4” elbow hose outlet(s) with 1-1/4” x 1”
reducer bushing.
Note: Union & riser pipe not supplied for
remote units.
Self-Contained unit available (up to 40gph)
Options
Local Preset (Attendant Preset)
Debit/Credit card reader (single display per
side models only).
Programmable Dual Pulse Output Board to
interface to fleet management systems &
tank monitoring system if RS485 is not used.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Explosion-proof junction box for lower
hydraulic area.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment.
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder).
Custom lower door colors and/or graphics.
Hoses, nozzles, swivels.
Satellite-in-use light(s) for remote master.
Satellite pipe kit installed in remote master.
Companion Satellites (Full size Big Fueler
styling in low or high hose models. Singles
or duals, one or two sided. Note: a dual can
be one or two sided).
Companion Satellites (LPS Economy low
hose models in single or dual style. Note:
duals are two sided only).
For further details about satellite models, see
our Product Cut Sheet for Satellites.
For information on flow rates and model
configurations see our Price Lists.
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device
(e.g. Trendar, VeriFone).
RS485 interface or current loop or dual pulse
output (i.e. 4-pulse output channels).
Exclusive eCal
TM
(Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Back lighted 1-inch LCD displays.
Satellite Outlet Connection.
Single Master, dual master, master/satellite
combination, & master-master/satellite-
satellite dual combination.
Field configurable for single point or
simultaneous master & satellite fueling.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design.
Front or side mount nozzle boots.
Heavy duty lift-to-start nozzle boots
accommodate high speed truck stop nozzles.
Long-life cabinet using galvanneal
components and powder coated panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Optional color lower doors - hinged, swing
out.
Heavy duty hose hook for low hose models.
Computer
Simplified single board design electronics.
Includes CPU, power, display, eCal, RS485
or current loop connection, electromechanical
analog totalizer, push-button programming
switches, wiring terminal strip.
LED Backlighting board for the LCD display.
Magnetic drive, tamper-proof pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lit LCD display,
1” (2.54cm) numerals for money & volume;
1/2” (1.27cm) numerals for price-per-volume.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale &
volume totals.
Current loop Bennett fuel protocol interface.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Built-in diagnostics with error codes.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
interference.
Electronic 3000 Series SPEC. 100
Retail Big Fueler Series Models (Money & Volume) - High Flow
