120001 Rev K 1-19-18
Pulse Output Field Wiring Table
(Also refer to as the Pulse Output Wiring Diagram)
Name Color Wire
Size
J-Box Connection
(Optional)
Board Connection
Tank Gauge Out Product A side 1
(+)
Gray 1(+) 18 Ga. Flying Lead Gray Product A
Marked 1(+)
TS1-3 Pulse Output Board Product A
Tank Gauge Out Product A side 1
(-)
Gray 1(-) 18 Ga. Flying Lead Gray Product A
Marked 1(-)
TS1-4 Pulse Output Board Product A
Tank Gauge Out Product A side 2
(+)
Pink 1(+) 18 Ga. Flying Lead Pink Product A
Marked 1(+)
TS1 - 7 Pulse Output Board Product A
Tank Gauge Out Product A side 2
(-)
Pink 1(-) 18 Ga. Flying Lead Pink Product A
Marked 1(-)
TS1– 8 Pulse Output Board Product A
Pulse Output Product A side 1
(+)
Red (+) 18 Ga. Position 1 in J-Box TS1-1 Pulse Output Board Product A
Pulse Output Product A side 1
(-)
Red (-) 18 Ga. Position 2 in J-Box TS1-2 Pulse Output Board Product A
Pulse Output Product A side 2
(+)
Orange (+) 18 Ga. Position 3 in J-Box TS1-5 Pulse Output Board Product A
Pulse Output Product A side 2
(-)
Orange (-) 18 Ga. Position 4 in J-Box TS1-6 Pulse Output Board Product A
Handle Product A side 1
(+)
Violet 1(+) 18 Ga. Position 5 in J-Box TS2-9 Pulse Output Board Product A
Handle Product A side 1
(-)
Violet 1(-) 18 Ga. Position 6 in J-Box TS2-10 Pulse Output Board Product A
Handle Product A side 2
(+)
Blue 1(+) 18 Ga. Position 7 in J-Box TS2-11 Pulse Output Board Product A
Handle Product A side 2
(-)
Blue 1(-) 18 Ga. Position 8 in J-Box TS2-12 Pulse Output Board Product A
Authorization Product A side 1
Brown 1A 18 Ga. Position 9 in J-Box TS3 - 13 Pulse Output Board Product A
Authorization Product A side 2
Brown 1B 18 Ga. Position 10 in J-Box TS3 -15 Pulse Output Board Product A
Neutral Product A side 1
White (1) 18 Ga. Position 11 in J-Box TS3-14 & 16 Pulse Output Board Product A
Pulse Output Product B side 1
(+)
Yellow (+) 18 Ga. Position 12 in J-Box TS1-1 Pulse Output Board Product B
Pulse Output Product B side 1
(-)
Yellow (-) 18 Ga. Position 13 in J-Box TS1-2 Pulse Output Board Product B
Pulse Output Product B side 2
(+)
Black (+) 18 Ga. Position 14 in J-Box TS1-5 Pulse Output Board Product B
Pulse Output Product B side 2
(-)
Black (-) 18 Ga. Position 15 in J-Box TS1-6 Pulse Output Board Product B
Handle Product B side 1
(+)
Violet 2(+) 18 Ga. Position 16 in J-Box TS2-9 Pulse Output Board Product B
Handle Product B side 1
(+)
Violet 2(-) 18 Ga. Position 17 in J-Box TS2-10 Pulse Output Board Product B
Handle Product B side 2
(+)
Blue 2(+) 18 Ga. Position 18 in J-Box TS2-11 Pulse Output Board Product B
Handle Product B side 2
(-)
Blue 2(-) 18 Ga. Position 19 in J-Box TS2-12 Pulse Output Board Product B
Authorization Product B side 1
Brown 2A 18 Ga. Position 20 in J-Box TS3-13 Pulse Output Board Product B
Authorization Product B side 2
Brown 2B 18 Ga. Position 21 in J-Box TS3-15 Pulse Output Board Product B
Neutral Product B side 2
White (2) 18 Ga. Position 22 in J-Box TS3-14 & 16 Pulse Output Board Product B
Tank Gauge Out Product B side 1
(+)
Gray 2(+) 18 Ga. Flying Lead Gray Product B
Marked 2(+)
TS1- 3 Pulse Output Board Product B
Tank Gauge Out Product B side 1
(-)
Gray 2(-) 18 Ga. Flying Lead Gray Product B
Marked 2(-)
TS1-4 Pulse Output Board Product B
Tank Gauge Out Product B side 2
(+)
Pink 2(+) 18 Ga. Flying Lead Pink Product B
Marked 2 (+)
TS1-7 Pulse Output Board Product B
Tank Gauge Out Product B side 2
(-)
Pink 2(-) 18 Ga. Flying Lead Pink Product B
Marked 2 (-)
TS1-8 Pulse Output Board Product B
To Next Page
