Determine the model number of the dispenser from the serial plate located on the dispenser. Utilizing
the chart below determine the features of the dispenser to be installed. Understanding the features of
the dispenser to be installed will be helpful in understanding the proper installation of the dispenser.
How a Model for the 3000 Series Dispensers is Made Up.
Pump Model Retail Commercial Electronics Flow Rate # Products # Hoses
Motor
See Note 1
See Note 2
3711
X
531 Package All 1 1
3712
X
531 All 1 2
3722
X
531 All 2 2
3724
X
531 All 2 4
See Note 2
3811
X
210 Package All 1 1
3812
X
210 All 1 2
3822
X
210 All 2 2
3824
X
210 All 2 4
Note 1 - Flow Rate -
Standard - *23gpm (Remote) , 15 gpm (Self Contained)
Heavy Duty Suction - 24 gpm
Big Fueler Suction - 35 gpm (nominal with one hose active, 40 gpm total with Master and Satellite in
simultaneous flow ) with 1-1/2” valve.
Big Fueler Remote - 35 gpm (nominal with one hose active, 50 gpm total with Master and Satellite in
simultaneous flow) with 1-1/2” valve.
*Flow rates are “nominal” under ideal test conditions without accounting for system restrictions such as
hanging hardware. Actual flow rates will vary depending on conditions of installation.
Note 2 - Motor -The hydraulic arrangement can be as follows-
Remote
(submerged pump)
Standard/Heavy Duty
Suction with (1 Horse Power) Standard 1 phase 115/230 VAC 50/60 Hz
Suction with (1 Horse Power) Standard 1 phase 115/230 VAC 50/60 Hz with prepay valves
Suction with (1 Horse Power) 3 phase 380 VAC 50 Hz
Suction with (1 Horse Power) 3 phase 380 VAC 50 Hz with prepay valves
Big Fueler
Suction with (2 Horse Power) 1 phase 230 VAC 50/60 Hz with prepay valves
Suction with (2 Horse Power) 3 phase 380 VAC 50/60 Hz with prepay valves
Determining the Model Number
