Bennett 3722 - Page 6

6
120001 Rev K 1-19-18
Hydraulics
Rotary meter rated at 70gpm maximum.
Built-in inlet check valves to keep the
hydraulics full and prevent meter/pulser count
-up when the submersible pump pressurizes
the system.
1-1/2” 2-Stage prepay/preset electric
solenoid valve.
Dual spin-on filters
1-1/4” elbow hose outlet(s) with 1-1/4” x 1”
reducer bushing.
Note: Union & riser pipe not supplied for
remote units.
Self-Contained unit available (up to 40gph)
Options
Programmable dual channel, dual hose
Pulse Output Board to interface to fleet
management systems & tank monitoring
system if RS485 is not used.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Explosion proof junction box for lower
hydraulic area.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment).
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder.
Custom lower door colors and/or graphics.
Hoses, nozzles, swivels.
Satellite-in-use light(s) for remote master.
Satellite pipe kit installed in remote master.
Companion Satellites (Full size Big Fueler
styling in low or high hose models. Singles
or Duals, One or two sided. Note: a dual
can be one or two sided.).
Companion Satellites (LPS Economy low
hose models in single or dual style. Note:
Duals are two sided only.).
For further details about satellite models, see
our Product Cut Sheet for Satellites.
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device.
RS485 interface.
Exclusive eCal
TM
(Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Back lighted LCD displays.
Satellite Outlet Connection.
Remote dispensers only.
Single Master, dual master, master/satellite
combination, & master-master/satellite-
satellite dual combination.
Field configurable for single point or
simultaneous master & satellite fueling.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design
Front or side mount nozzle boots.
Heavy duty lift-to-start nozzle boots
accommodate high speed truck stop nozzles.
Long-life cabinet construction using
galvanneal components and powder coated
panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Green lower doors (optional colors available)
- hinged, swing out.
Heavy duty hose hook for low hose models.
Computer
Simplified single board design electronics.
Includes CPU, power supply, display, eCal,
RS485 connection, electromechanical analog
totalizer, push-button programming switches,
wiring terminal strip.
LED Backlighting board for the LCD display.
Magnetic drive, tamper-proof pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lighted LCD
display, 1” (2.54cm) numerals.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale
and volume totals.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Computer (cont’d)
Transaction display of: 999.999 for gallons,
9999.99 for liters.
Electronic hose totals of:
99999999.999 for gallons (8.3)
999999999.99 for liters (9.2)
Electromechanical totalizer 9999999.
Built-in diagnostics with error codes.
For information on flow rates and
model configurations see our
Price Lists.
UL
TM
listed.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Bennett dispensers may dispense
“Av-Gas”, but cannot dispense Jet
Fuel to fuel jet aircraft.
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
Electronic 3000 Series SPEC. 100
Commercial Big Fueler Series Models (Volume Only) - High Flow
