Q7T3-FP737S Dual function LCD Monitor Service Guide
Alignment Procedure
4
Confidential
User mode to factory mode 1A 5A XX checksum
Auto Color (Offset1, Offset2, Gain) 1B 5A XX checksum
Factory mode to User mode 1E 5A XX checksum
Clear user area data 1F 5A XX checksum
On burn in mode CE 1 XX checksum
Off burn in mode CE XX* XX checksum
Change Language Setting 66 0~7 XX checksum
*: Any value except 1 can off burn-in mode
Read EEPROM Bank-0 B0 Address XX checksum
Read EEPROM Bank-1 B1 Address XX checksum
Read EEPROM Bank-2 B2 Address XX checksum
Read EEPROM Bank-3 B3 Address XX checksum
Read EEPROM Bank-4 B4 Address XX checksum
Read EEPROM Bank-5 B5 Address XX checksum
Read EEPROM Bank-6 B6 Address XX checksum
Read EEPROM Bank-7 B7 Address XX checksum
Write EEPROM Bank-0 B8 Address Data checksum
Write EEPROM Bank-1 B9 Address
Data
checksum
Write EEPROM Bank-2 BA Address Data checksum
Write EEPROM Bank-3 BB Address Data checksum
Write EEPROM Bank-4 BC Address Data checksum
Write EEPROM Bank-5 BD Address Data checksum
Write EEPROM Bank-6 BE Address Data checksum
Write EEPROM Bank-7 BF Address Data checksum
Note A: Byte4(Checksum) = Byte1 + Byte2 + Byte3
Note B: Data = The value write to MCU
Note C: XX = don't care, any value(<=0xFF).
Note D: The Byte-2 definition of “Change Language Setting” is as below,
0=DE, 1=EN, 2=ES, 3=FR, 4=IT, 5=JA, 6=繁中, 7=簡中
When PC Host sends 0x7D command to MCU, MCU must return as following (2 bytes)
Return Code R-Byte1 R-Byte2
Checksum error code FC AA
N
ormal return code
the above Byte3
(/data) FC
If normal return code is exact FCh FC CF
The Table is for alignment machine to read data from EEPROM to check if the alignment process and
write data are correct.
