Q7T3-FP737S-Dual function LCD Monitor Service
Engineering Specification
15
Confidential
3.7 Panel optical Characteristics
Item Unit Conditions Min. Typ. Max.
Horizontal (Right)
CR = 10 (Left)
60
60
70
70
-
Vertical (Up)
CR = 10 (Down)
60
60
70
70
-
Horizontal (Right)
CR = 5 (Left)
70
70
80
80
-
-
Viewing Angle [degree]
Vertical (Up)
CR = 5 (Down)
70
70
80
80
-
-
Contrast ratio
Normal Direction
300
450
-
Raising Time
-
4
5
Falling Time
- 12 20
Response Time (Note 1)
[msec]
Raising + Falling
- 16 25
Red x
0.61 0.641 0.67
Red y
0.31 0.342 0.37
Green x
0.26 0.292 0.32
Green y
0.58 0.611 0.64
Blue x
0.11 0.147 0.17
Color / Chromaticity
Coordinates (CIE)
Blue y
0.04 0.068 0.10
White x 0.28
0.313
0.34
Color Coordinates (CIE) White
White y 0.30
0.329
0.36
White Luminance @ CCFL 7.0mA
(center)
[cd/m
2
]
200 260 -
Luminance Uniformity (Note 2)
[%] 75 80 -
Crosstalk (in 75Hz) (Note 3)
[%] 1.5
Note
1. Viewing Angle, Contrast Ratio, Response Time, Reflectance, and Chromaticity are measured at panel center.
2. Viewing Angle(θ, ψ)
