-Corner 5-3-2 select at weakness side [the low left (or right) corner of the front panel]
-An edge drop with impact on the shortest edge radiating from corner 5-3-2
-An edge drop with impact on the next shortest edge radiating from corner 5-3-2
-An edge drop with impact on the longest edge radiating from corner 5-3-2
-A flat drop with impact on the rear
-A flat drop with impact on the front
-A flat drop with impact on the right
-A flat drop with impact on the left
-A flat drop with impact on the bottom
-A flat drop with impact on the top
After test, there is no electrical and mechanical damage permitted.
2.2.3 HALF-SINE SHOCK
Test conditions:
Test unit: 2 sets
Each unit has to withstand 18 shocks.(3 shocks pre face)
No- operation
Half-sine wave
Duration: 3ms
Acceleration (G): 75G
2.3 Packing Configuration
2.3.1 Container Specification
a. Shipping Container
Container Type
20'*8'*8'6
" Steel
40'*8'*8'6" Steel 40'*8'*9'6"
High Cube Steel
Gross 24,000 30,480 30,480
Weight (Kegs) Tare 2,370 4,000 4,200
Payload 21,630 26,480 26,280
Length 5,898 12,031 12,031
Width 2,352 2,352 2,352
Interior Measurement (mm)
Height 2,394 2,394 2,699
Volume (Cubic Meter) 33.2 67.74 76.4
Width 2,340 2,340 2,340
Door opening (mm)
Height 2,280 2,280 2,585
