4.1.4 Brightness Adjustment Range
At contrast ratio control set at maximum level, adjusting Brightness control from minimum to maximum position,
the light output of WHITE pattern shall be increased more than 40cd/
㎡
.
5. Physical Specifications
5.1 Physical Dimension & Appearance
5.1.1 Overall Dimensions:
375mm (W) X 370mm (H) X 155mm (D)
5.1.2 Outer Appearance:
see Fig.1
5.2 Construction and Materials on outer surface
(1) Materials: Plastic
5.3 Base
(1)Tilt: fiest hinge:0°~ 25° , second hinge : 25
°
~135
°
5.4 Marking & Labels
5.4.1 Reference Label (Rear panel)
(1) Reference numbers
(2) Manufacture data
(3) Agency Approvals
(4) Power Ratings
5.4.2 Controls & Connectors
(1) DC power adapter input: abbreviated labels
(2) User's Controls: standard print
5.5 Packaging
5.5.1 Carton Dimension:
385mm (W) X455mm (D) X 1478mm (H) (LCD monitor)
5.5.2 Shipping Weight: 6.2kg
(LCD monitor)
5.5.3 Shipping Container:
2100
sets per 40 feet container with pallet.
6. Maintainability Specifications
6.1 General & Requirements
6.1.1 Installation:
From outside of unit with standard tools and documentation provided to user.
6.1.2 Periodic Maintenance:
No periodic maintenance is required.
6.1.3 Repair & Calibration:
Require spare modules or components as specified as followings:
(1) Interface board ASSY
(2) AC-DC converter board ASSY
(1) Control board ASSY
6.2 Mean Time to Repair
6.2.1 Module Level:
Less than 10 minutes
6.2.2 Component Level:
Less than 15 minutes
