Q7T3(AUO panel) LCD Monitor Service Guide
Engineering Specification
10
832X624 49.72(N) 74.55(N) 57.29 Macintosh
*1024x768 48.36(N) 60.00(N) 65.00 VESA
1024x768 56.48(N) 70.10(N) 75.00 VESA
*1024x768 60.02(P) 75.00(P) 78.75 VESA
1024X768 60.24(N) 74.93(N) 80.00 Macintosh
1152x864 67.50(P) 75.00(P) 108.00 VESA
*1152x870 68.68(N) 75.06(N) 100.00 Macintosh
1152x900 61.80(N) 66.00(N) 94.50 SUN 66
1152x900 71.81(N) 76.14(N) 108.00 SUN
*1280x1024 64.00(P) 60.00(P) 108.00 VESA
1280x1024 75.83(N) 71.53(N) 128.00 IBM1
*1280x1024 80.00(P) 75.00(P) 135.00 VESA
*1280x1024 81.18(N) 76.16(N) 135.09 SPARC2
3.3 Number of display colors: 226K color numbers
3.4 Adjustment function
Luminance:
Brightness
Contrast
Geometry:
H. Position
V. Position
Pixel Clock
Phase
Color gain (Red, Green, Blue)
OSD:
H. Position
V. Position
OSD Time
Multi-language selection
Recall function:
Position Recall
Color Recall
Recall All
Miscellaneous:
Display Information.
OSD Halftone
3.5 Display Power Management System (DPMS)
This Interface board will automatically cut down the power of the monitor when not receiving HSYNC or VSYNC
signals over about 5 seconds, and the condition are as below,
HSYNC VSYNC LCD Module Backlight
Pulse Pulse On On
No pulse Pulse Off Off
Pulse No pulse Off Off
No pulse No pulse Off Off
