Q7T3(AUO panel) LCD Monitor Service Guide
Engineering Specification
7
Width 890 1335 890
1335
Dimension (mm)
Height 115 115 115
115
Length X X X
X
Width X X X
X
Air Transport Pallet
Dimension (mm)
Height X X X
X
2.3.4 Container Carrying Capacity
a. Shipping Container
Quantity of products
(sets)
Quantity of Products
(sets)
Quantity of pallet
(sets)
Stowing Type
(Every container) (Every Pallet) (Every Container)
1050
Pallet A: 56 Pallet A: 6
20'
Pallet B: 84 Pallet B: 6
Pallet C:84 Pallet C: 1
Pallet D:126 Pallet D: 1
40'
2100
Pallet A: 56 Pallet A: 15
with pallet
Pallet B: 84 Pallet B: 15
2.4 Electrostatic Discharge Requirements
The subject product must withstand 8KV for contact discharge and 15KV for air discharge of
Electrostatic Discharge and meet the acceptance criteria as specified in XXXISO 9241-3XXX -- should be
IEC 801-2.
2.5 Safety Requirements
The display unit complies with the following safety standards and specifications.
- UL compliance.... standard for information-processing and business equipment, UL 1950.
- CSA compliance...standard C22.2 No. 950-M89, data processing equipment.
- TUV compliance...EN60950 safety specification-business equipment.
- ISO13406-2. Ergonomic Requirements of Visual Display.
2.6 EMI Requirements
1. This display unit complies with the following EMC rules and regulations.
-FCC compliance...FCC Rule, Part 15, Subpart B, Class B.
-VCCI compliance...VCCI Rule, Class-2.
-CE Mark Compliance... 89/336/EEC.
EN55024, EN61000-4-2/-3/-4/-5/-6/-8/-11
EN55022, Class B.
EN61000-3-2, EN61000-3-3.
-DNSF compliance...EN55022, Class B.
-MPR2 compliance
-TCO99
-C-Tick
-BSMI
-EPA
