Q7T3(AUO panel) LCD Monitor Service Guide
Engineering Specification
3
1. Introduction
This specification describes a 17.0” color TFT LCD monitor which is supported by analog interface solution and support
maximum resolution 1280X1024 at 75Hz refresh rate. It has the following features:
- User controls:
(a) “Power on/off” switch.
(b)
“Menu” key: For enter sub-menus or select items.
(c) " EXIT "key: back to main menus
、
leave OSD or enter volume hot-key function.
(d) "
3
" key: For left adjustment and enter “Contrast” Hot-key function.
(e) "
4
" key: For right adjustment and enter “Brightness” Hot-key function.
(f) “I-Key”: For auto-adjustment picture.
- OSD window for control and information display with 8 languages selection.
- DPMS (Display Power Management System)
- Power on/off indicator.
- Tilt base (with tilt function from 0 to +25 degree).
-DDC2B function supported.
It is composed of the following materials:
-A LCD monitor
(a) Head part:
(1) A LCD module (AU M170EN05).
(2) An Inverter +AC-DC board
(3) An Interface board.
(4) A control board.
(5) A 15pin D-sub connector
(b) Base part:
(1) Tilt base.
- A power cord
- An user menu.
2. Operational Specification
2.1 Environment
2.1.1 Temperature
-Operating +0 to +40 degrees Celsius
-Non-operating -20 to +60 degrees Celsius
2.1.2 Humidity
-Operating 10 to 90% Max. Non-condensing
-Non-operating 10 to 95% Max. Non-condensing
2.1.3 Altitude
-Operating 0 to 3,048m (10,000ft)
-Non-operating 0 to 12,192m (40,000ft)
2.2Transportation
2.2.1 Vibration Test (Package, Non-Operating)
