BenQ TK700ST - Controls and Functions; Projector & Remote Control

9 Introduction
Controls and functions
Projector & Remote control
1. POWER
Toggles the projector between standby
mode and on.
ON/ OFF
Toggles the projector between standby
mode and on.
2. POWER indicator light/TEMPerature
warning light/LIGHT indicator light
(See Indicators on page 46.)
3. IR remote sensor
4. BACK
Goes back to previous OSD menu, exits
and saves menu settings.
5. Arrow keys ( , , , )
When the On-Screen Display (OSD) is
activated, these keys are used as
directional arrows to select the desired
menu items and to make adjustments.
When OSD menu is inactive, workable
under CEC-capable sources only.
6. /SOURCE
Displays the source selection bar.
7. ECO BLANK
Used to hide the screen picture.
Do not block the projection lens from
projecting as this could cause the blocking
object to become heated and deformed or
even cause a fire.
8. OK
Confirms the selected On-Screen Display
(OSD) menu item.
9. MODE/PIC MODE
Selects an available picture mode.
10. MENU
Turns on/off the On-Screen Display (OSD)
menu.
2
9
7
6
8
5
1
3
4
10
All the key presses described in this
document are available on the remote control
or projector.
7
1
9
5
11
15
6
16
4
10
12
13
14
8
