Specifications 52
• XXXX: Support auto-detect 3D and manually set 3D format. If source can output CEA861 720p/1080p and
color space is RGB with 3D info frame then 3D auto detect function is also workable.
• XXX: Support manually set 3D format.
• XX: Support manually set 3D format (HDMI receiver or scaler down scaling 4K content to 1080p).
• Video timings
1920x1080
@240HZ
1920X1080_
240
240 270 594 Yes
3840x2160
3840x2160_
30 For 4K2K
model
30 67.5 297 Yes
3840x2160
3840x2160_
60 For 4K2K
model
60 135 594 Yes
Resolution Mode
Refresh
rate
(Hz)
H-
frequency
(kHz)
Clock
(MHz)
User
Manual
Supported
3D Field
Sequential
3D
over-
under
3D
side-
by-side
The timings showing above may not be supported due to EDID file and VGA graphics card limitations. It is
possible that some timings cannot be chosen.
Timing Resolution
H
frequency
(KHz)
V
frequency
(Hz)
Dot clock
frequency
(MHz)
3D Field
Sequential
3D frame
3D
over-
under
3D
side-
by-side
480i
720(1440) x
480
15.73 59.94 27
480p 720 x 480 31.47 59.94 27
576i
720(1440) x
576
15.63 50 27
576p 720 x 576 31.25 50 27
720/50p 1280 x 720 37.5 50 74.25 XXXX XXXX XXXX
720/60p 1280 x 720 45 60 74.25 XXX XXXX XXXX XXXX
1080/24P 1920 x 1080 27 24 74.25 XXXX XXXX XXXX
1080/25P 1920 x 1080 28.13 25 74.25
1080/30P 1920 x 1080 33.75 30 74.25
1080/50i 1920 x 1080 28.13 50 74.25 XXXX
1080/60i 1920 x 1080 33.75 60 74.25 XXXX
1080/50P 1920 x 1080 56.25 50 148.5 XXXX
1080/60P 1920 x 1080 67.5 60 148.5 XXX XXXX XXXX
1080/120p 1920x1080 135 120 297
1080/240p 1920x1080 270 240 594
2160/24P 3840 x 2160 54 24 297
2160/25P 3840 x 2160 56.25 25 297
2160/30P 3840 x 2160 67.5 30 297
2160/50P 3840 x 2160 112.5 50 594
2160/60P 3840 x 2160 135 60 594
