56 Universal Cellular Communicator
See the following tables.
 The following must be configured: an event for sending the Alarm/Tamper Contact ID, in case of activation of input 1, and an
event for sending the Fault Contact ID in case of activation of input 2.
Communicator Panel
LI

LE
T1: PSTN Fault output
T2: No Cellular Network output
Factory setting
T3: Interconnection Present

LE Detection output
T4: Tamper output

Communicator Tamper input
T5: GSM Fault output

GSM Fault input
T6: IP Receiver Communications Failure output

IP Receiver Communications Failure input
Table 13 – Connection scheme A: simulated PSTN.
Communicator Panel
Factory setting
T1: Alarm/Tamper input

Alarm/Tamper output
T2: Fault input

Fault output
T3: Interconnection Present

Interconnection Present input
T4: Tamper + Jamming output

Communicator Tamper input
T5: GSM Fault output

GSM Fault input
T6: IP Receiver Communications Failure output

IP Receiver Communications Failure input
Earth terminal

Earth terminal
Table 14 – Connection scheme B: without simulated PSTN.
