Bentel Security B3G-220 - Network Settings

220 Series 43
 Enquiry Interval: enter the interval within which the periodic SMS is to be sent with the balance information (if handled by
the operator). The interval is composed of the following values:
— Days, day of next send—select to send the next periodic SMS. The value runs from 0 to 364;
— Hours, time of next send—select to send the next periodic SMS. The value runs from 0 to 23.
SIM Expiration
 SIM Expiration Message: enables sending the SMS (user programmable) with the expiration data to the first number in
the phonebook.
 SIM Expiration Date: once the expiration date is set, the message is sent 30, 15, 7, 6, 5, 4, 3, 2 and 1 days prior to the
expiry date itself. Click on Now to set the PC's time.
 The SMS is sent once every programmed day: if it fails, no further attempt is done.
Protocol Settings
 Handshake Repetition: set the number of handshakes generated by the communicator and sent to the panel connected
to terminals LI. Range: 1 to 4.
 Communication protocol: select the protocol: Contact ID or SIA.
 Depending on this setting, the communicator will decode CID or SIA events from the panel connected to the LI line; the setting
must be the same for all numbers handled by the communicator.
The installer must check that the operator (Wind, Tim, Vodafone, etc.) works reliably with CID (Contact ID) on the GSM
network, due to issues with transmission quality.
Network Settings
This page is used for starting a session / programming remotely
 Device ID: enter the Communicator's serial number you can find on the Communicator’s electronic board.
 Remote Access: check this box to enable remote programming.
 Remote Access APN: access point name, up to 32 characters. This is generally supplied by the cellular network operator.
 Remote Access User Name: some operators require user authentication; enter the user name in this field.
 Remote Access Password: enter the password in this field.
 See paragraph “Start a remote session” on page 34.
