BENTONE
6. Pump A2L 65 CK/A2L 75 CK
6.1 Technical data
One or two-pipe system
Viscosity range:: 2-12 mm
2
/s
Pressure range:: 8-15 bar
Rated voltage of coil: 220/240V 50/60 Hz
Oil temperature:: max 60°C
1. Suction line G 1/4”
2. Return plug
3. Nozzle outlet G 1/8” Stage 2 and Stage 1
4. Pressure gauge port G 1/8”
5. Vacuum gauge port G 1/8”
6. Pressure adjustment
7. Solenoid valve 1
8. Solenoid valve 2
165 105 10-2
6.2 Components
