BENTONE
2.3 Working eld
2.4 Basic settings - Fuel oil
Basic settings should only be seen as setting values to get burner to start.
Once the burner has started and established ame, it is necessary to adjust the
settings so that they are adapted to the installation and the fuel used.
!
Do not exceed working
eld.
-1
0
1
2
3
4
5
6
7
8
9
100 150 200 250 300
mbar
kW
9.3-27.0 kg/h 110-320 kW
160302-625-4
0
20
40
60
80
100
0
2
4
6
8
10
100 140 180 220 260 300 340
160303-176-2
kW
Air settings
Nozzle assembly
Scale
1
Burner output
Air
2
<˚
1
Scale nozzle assembly and air damper without damper motor.
2
Settings air damper with damper motor.
