7 Bentone
2.3 Working eld
d
1
d
2
d
3
d1 d2 d3
ø 115 (130) 14 ø 200-250
2.4 Setting for nozzle assembly and air damper
0
20
40
60
80
100
0
2
4
6
8
10
110 150 190 230 270 310 350
160303-189-2
kW
Air settings
Nozzle assembly
Scale
1
Burner output
Air
2
<˚
1
Scale nozzle assembly and air damper without damper motor.
2
Settings air damper with damper motor.
!
Do not exceed working
eld.
-1,0
0,0
1,0
2,0
3,0
4,0
5,0
100 150 200 250 300 350
mbar
kW
9.0-29.5 kg/h
107-350 kW
160303-402
2.2 Burner installation
2.2.1 Hole patten
Make sure the hole pattern on the boiler is designed for burner ange.
