Bentone BF1 RME - 1.1 Model BF1 FUV 63-16; 1.1.1 Burner Output and Basic Settings

6
Bentone BF1
General
ø63
ø67
ø16
7,0–8,0
1,6–2,0
(-0,1)+0,5
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60
Burner output, kW
Boiler overpressure, mbar
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
15 20 25 30 35 40 45 50 55
Burner output, kW
Scale
Air settings
Nozzle assembly
!
Scale value applies to 0 mbar furnace pressure.
1.1 Model BF1 FUV 63-16
Length of blast tube
Protrusion from flange, measurement B
Flange
1 2 3 4
103 68 81 89 88
133 98 111 119 118
183 148 161 169 168
1.1.1 Burner output/ Basic settings
1,3 - 4,6 kg/h
15 - 55 kW
