Transport
124 - 131
Operating manual, Dumper – 3012 PLUS
Status 28 April 2015
Bergmann Maschinenbau GmbH & Co. KG
11.3.4. Manually lowering trough in the event of a hydraulic failure
If the vehicle needs to be towed and the trough can no longer be lowered hydraulically (e.g. due to a
failure of the diesel engine or the electronics), the trough must be lowered manually. To do this, you must
operate the respective valve manually.
Top view
Fig. 11-18
The valve is located under the bonnet to the
right of the diesel engine (see figure to the left).
All electronic and mechanical adjustments
must be carried out by authorised technical
personnel.
WARNING
