Transition duct is designed to be
separated by cutting at the bevels.
Removing this flare will allow the 90
degree elbow to slide inside the stealth
providing 360 degrees of rotation.
Secure with self-drilling screws.
Install the NITE Phoenix Unit Power
Harness Grommet. Chose a good
location for the flanged grommet
provided. Drill a 2″ hole and install
provided grommet in the floor. Route
all Phoenix and heater cables through
this grommet. Secure harness with
provided zip ties.
Install Drip Tube Under Truck.
Notice deflector pan has be modified to
allow proper air flow
Failure to use the proper cable loom and/or grommet will result in damage to cables, unit and/or
vehicle. Always seal all open areas in grommet with silicone when installation is complete.
Silicone is not provided in kit.
