Attach Stealth to the NITE Duct.
After the controls are installed and the
stealth is cut and rotated 90° fasten the
stealth to the NITE Phoenix duct using
four 1″ X 5/16 self-tapping screws.
Apply silicone sealant around seam.
Duct shown has been cut and rotated 90
degrees. See instructions page 1-22.
NOTE: Silicone sealant is not included
in kit.
Attach NITE Phoenix Duct to Back
Wall of Sleeper. Press the top of the
duct up against the back wall. Make
sure the duct is square and level against
the back wall. Use 1″ X 5/16 hex head
self-tapping screws to attach top of duct
to back wall. Place 3 - 5 screws in each
duct opening and install at different
angles (A). Take care not to over
tighten. Snap both louvers into place
(B).
Attach Flex Hose to Stealth and
Elbow. Secure with 4″ clamps.
