Connect the assembled connector to the
existing connector on the Terra Power
switch
Complete Electrical Wiring
Recheck and tighten all battery and
separator connections. Zip tie cables
where necessary. Your wiring should look
like the diagram on page 5-1.
This completes the electrical section of the installation. If you are installing the
ESPAR heater proceed to section 3. If you are installing the WEBASTO heater
proceed to section 4. If you are not installing an aftermarket heater, your
installation is complete and you may reconnect the truck batteries.
WARNING: If you have a fuel operated heater that was installed at the
factory or prior to the Phoenix install, you can continue to operate the
heater with the existing controller.
IF you choose to wire the existing factory installed heater to the Phoenix
controller, YOU WILL VOID THE FACTORY WARRANTY OF THE
HEATER!
