Berkel BSFTM - Dimensions, BSFM Series; Specifications, BSFM Series

UM - CODE N1 N2 N3 N9 - REV 0.3
3.3. Dimensions, BSFM series
3.4 Specifications, BSFM series
Models
BSFMM BSFML BSFMX
Capacity (round)
213 mm 240 mm 272 mm
Capacity (rectangle)
253 x 178 mm 270 x 210 mm 320 x 232 mm
Maximum slice thickness
17 mm 17 mm 17 mm
Knife diameter
280 mm 315 mm 360 mm
0,18 kW / 230 V 50 Hz 1 phase 0,24 kW / 230 V 50 Hz 1 phase 0,55 kW / 230 V 50 Hz 1 phase
0,27 kW / 400 V 50 Hz 3 phases 0,27 kW / 400 V 50 Hz 3 phases 0,55 kW / 400 V 50 Hz 3 phases
Base dimensions
470 x 380 mm 524 x 427 mm 602 x 476 mm
Net weight
35 kg 40 kg 46 kg
Motor rating/Electrical specifications
10
Models
BSFMM BSFML BSFMX
A 178 mm 210 mm 232 mm
B 253 mm 270 mm 320 mm
C 213 mm 240 mm 272 mm
D 505 mm 634 mm 650 mm
E 326 mm 377 mm 430 mm
F 590 mm 620 mm 667 mm
G 450 mm 497 mm 565 mm
H 413 mm 453 mm 534 mm
I 663 mm 726 mm 818 mm
L 690 mm 836 mm 962 mm
M 535 mm 777 mm 812 mm
A
C
B
G
D
E
F
L
H
M
I
