Berkel BSFTM - Dimensions, BSFS Series; Specifications, BSFS Series

UM - CODE N1 N2 N3 N9 - REV 0.3
ENGLISH
3.5. Dimensions, BSFS series
3.6 Specifications, BSFS series
11
Models
BSFSM BSFSL BSFSX
Capacity (round)
211 mm 240 mm 272 mm
Capacity (rectangle)
251 x 176 mm 285 x 200 mm 310 x 245 mm
Maximum slice thickness
17 mm 17 mm 17 mm
Knife diameter
280 mm 315 mm 360 mm
0,18 kW / 230 V 50 Hz 1 phase 0,24 kW / 230 V 50 Hz 1 phase 0,55 kW / 230 V 50 Hz 1 phase
0,27 kW / 400 V 50 Hz 3 phases 0,27 kW / 400 V 50 Hz 3 phases 0,55 kW / 400 V 50 Hz 3 phases
Base dimensions
470 x 380 mm 524 x 427 mm 602 x 476 mm
Net weight
35 kg 40 kg 46 kg
Motor rating/Electrical specifications
Models
BSFSM BSFSL BSFSX
A 176 mm 200 mm 245 mm
B 251 mm 285 mm 310 mm
C 211 mm 240 mm 272 mm
D 445 mm 590 mm 610 mm
E 326 mm 377 mm 430 mm
F 538 mm 655 mm 758 mm
G 450 mm 497 mm 565 mm
H 413 mm 453 mm 534 mm
I 665 mm 740 mm 788 mm
L 765 mm 824 mm 874 mm
M 606 mm 693 mm 750 mm
C
A
B
G
E
F
D
L
M
H
I
