Berkel BSFTM - Dimensions, BSFT Series; Specifications, BSFT Series

UM - CODE N1 N2 N3 N9 - REV 0.3
12
3.7. Dimensions, BSFT series
3.8. Specifications, BSFT series
Models
BSFTM BSFTL BSFTX
A 178 mm 200 mm 242 mm
B 253 mm 285 mm 310 mm
C 213 mm 240 mm 272 mm
D 560 mm 620 mm 700 mm
E 326 mm 377 mm 430 mm
F 538 mm 655 mm 758 mm
G 450 mm 497 mm 565 mm
H 413 mm 453 mm 534 mm
I 665 mm 740 mm 788 mm
L 690 mm 760 mm 810 mm
M 530 mm 590 mm 680 mm
Models
BSFTM BSFTL BSFTX
Capacity (round)
213 mm 240 mm 272 mm
Capacity (rectangle)
253 x 178 mm 285 x 200 mm 310 x 242 mm
Maximum slice thickness
17 mm 17 mm 17 mm
Knife diameter
280 mm 315 mm 360 mm
0,18 kW / 230 V 50 Hz 1 phase 0,24 kW / 230 V 50 Hz 1 phase 0,55 kW / 230 V 50 Hz 1 phase
0,27 kW / 400 V 50 Hz 3 phases 0,27 kW / 400 V 50 Hz 3 phases 0,55 kW / 400 V 50 Hz 3 phases
Base dimensions
470 x 380 mm 524 x 427 mm 602 x 476 mm
Net weight
35 kg 40 kg 46 kg
Motor rating/Electrical specifications
B
C
G
A
D
E
F
L
H
M
I
