Berkel BSFTM - 3 Technical Characteristics; Dimensions, BSFG Series; Specifications, BSFG Series

UM - CODE N1 N2 N3 N9 - REV 0.3
ENGLISH
3. Technical characteristics
3.1. Dimensions, BSFG series
3.2 Specifications, BSFG series
9
Models
BSFGM BSFGL BSFGX
Capacity (round) 198 mm 230 mm 269 mm
Capacity (rectangle) 260 x 149 mm 282 x 185 mm 318 x 225 mm
Maximum slice thickness 17 mm 17 mm 17 mm
Knife diameter
280 mm 315 mm 360 mm
0,18 kW / 230 V 50 Hz 1 phase 0,24 kW / 230 V 50 Hz 1 phase 0,55 kW / 230 V 50 Hz 1 phase
0,27 kW / 400 V 50 Hz 3 phases 0,27 kW / 400 V 50 Hz 3 phases 0,55 kW / 400 V 50 Hz 3 phases
Base dimensions 470 x 380 mm 524 x 427 mm 602 x 476 mm
Net weight 29 kg 35 kg 41 kg
Motor rating/Electrical specifications
Models
BSFGM BSFGL BSFGX
A 149 mm 185 mm 225 mm
B 260 mm 282 mm 318 mm
C 198 mm 230 mm 269 mm
D 418 mm 670 mm 690 mm
E 326 mm 377 mm 430 mm
F 466 mm 593 mm 630 mm
G 418 mm 510 mm 540 mm
H 413 mm 453 mm 534 mm
I 707 mm 714 mm 805 mm
L 762 mm 833 mm 926 mm
M 560 mm 698 mm 788 mm
G
D
E
F
