Berkel BSFTM - Page 18

UM - CODE N1 N2 N3 N9 - REV 0.3
18
BSFT series
1. STOP BUTTON (RED)
2. START BUTTON (GREEN )
3. IDENTIFICATION PLATE, TECHNICAL DATA AND EC MARKING
4. LUBRICATING POINT FOR CARRIAGE GUIDES
5. SLICE THICKNESS REGULATING KNOB
6. THICKNESS PLATE
7. BLADE
8. SHARPENER
9. BLADE COVER
10. BLADE COVER TENSION ROD
11. BASE
12. SLICE DEFLECTOR
13. BLOCK
14. FEED CABLE
15. FEET
16. PLATE PUSHING HANDLE
17. PLATE SUPPORT
18. PLATE LOCKING KNOB
19. SLIDING OVERPLATE
20. FOOD PRESS
21. UNLOCKING LEVER FOR VERTICAL SLIDING
22. FOOD PRESS MANOUEVERING LEVER
22. PLATE
24. SAFETY RING (BLADE PROTECTION)
1
2
11
6
8
9
21
20
19
23
18
17
16
5
3
20
22
19
16
5
4
2
1
15
15
11
14
10
8
7
24
13
12
15
