Page 24 F00636
S.A.E. Engine Mount
Pump Nomenclature
Shaft
Sleeve
Balance
Ring
Balance Ring
Gasket
Packing
Grease
Cup
Lantern
Ring
Metallic
Ring
Packing
Gland
Packing
Rings
Volute
Case
Volute Gasket
or O-Ring
Wear
Ring
Impeller
Capscrew
Shakeproof
Lockwasher
Bracket
5532 1006
SAE 1: 12 Holes on 20.88" Bolt Circle
SAE 2: 12 Holes on 18.38" Bolt Circle
SAE 3: 12 Holes on 16.88" Bolt Circle
SAE 4: 12 Holes on 15.00" Bolt Circle
SAE 5: 8 Holes on 13.12" Bolt Circle
Impeller
Impeller
Washer
BERKELEY
Outer
Bearing
Cap
Pump
Shaft
Slinger
Oil Seal
Double Row
Thrust Bearing
Single Row
Bearing
Shoulder
Ring
Seal Retainer
O-Ring
or Gasket
Mechanical
Seal
L
L
Mechanical
Seal
Packing
Self-Priming
Centrifugal
Centrifugal
Clack
Weight
Rubber Clack
(Check Valve)
Clack
Washer
Suction
Cover
Pump Case
(Volute)
mpeller
Case Gasket
Impeller
Lock Nut
