7.4.2 Control and signaling terminal block
The control and signaling
terminal block (1) is located on
the top of the electronic
assembly.
1. Connect the control and
signaling wires (marked 1
to 13) on the upper
terminals.
2. Tighten the sealing nut on
the cable gland when you
have completed wiring.

 See Chapter 11 for more information on the wiring.
7.4.3 Internal ground terminal
The ground terminal is a metal
tab with a threaded hole located
under the terminal board at its
bottom.
