How to wire actuator with Positioner
The wiring must be done according to the wiring diagram of your
actuator.
 See Chapter 11 for more information on the wiring.
1. Using a 3×0.5 mm flat blade screwdriver, connect the power
supply on terminals marked L1, L2 & L3 (3Ph) or L, N (1Ph)
according to your supply type.
2. Crimp a ring cable lug on the ground cable.
3. Remove the screw using a 4 mm hex key.
4. Install a washer between the head of the screw and the ring
cable lug.
5. Tighten the screw.
6. Tighten the sealing nut on the cable gland when you have
completed wiring.
